single mode laser diodeS

Single mode laser diodes are Fabry-Perot Laser Diodes operating on a single transverse resonator mode. This leads to a diffraction-limited output beam. This type of laser diodes deliver high output power density since the beam is easily collimated. The frequencies are separated by the free spectral range of the resonator given by the reflecting facets of the laser chip. Multiple longitudinal modes may occur which can lead to differing optical frequencies. Wavelength can be selected and locked with fiber brag grating.

Single mode laser diodes are ideal light source for laser surface profiler (scanner/ interferometer), laser position sensor, optical tweezer and pump laser.

Our single mode laser diodes are available in compact and low cost TO9, free space butterfly window with beam collimation and TEC, single mode PM fiber output butterfly with TEC and compact flatpack window package.

Available wavelengths are 808 nm (up to 800 mW cw, single emitter), 850 nm (100 mW), and 1060 nm (up to 750 mW cw, single emitter).

The newly launched 400 mW single mode fiber pump at 808 nm provides the highest power delivery in the market from a single mode polarization maintenance fiber. This allows easy application in combination with fiber switches and combiners. Further wavelength selection and locking can be realized with FBG, please contact us for more information.

PRODUCT FINDER

Operational Mode

Results sorted by Wavelength:

EYP-RWL-0808-00400-4000-BFY02-0000Single Mode Laser Diode400mW SM

Wavelength: 808 nm
Power: 400 mW
Fabry Perot laser diode
CW

EYP-RWL-0808-00800-4000-BFW09-0000Single Mode Laser Diode

Wavelength: 808 nm
Power: 800 mW
Fabry Perot laser diode
CW

EYP-RWL-0850-00100-1500-SOT12-0000Single Mode Laser Diode

Wavelength: 850 nm
Power: 100 mW
Fabry Perot laser diode
CW

EYP-RWL-1060-00100-1300-SOT01-0000Single Mode Laser Diode

Wavelength: 1060 nm
Power: 100 mW
Fabry Perot laser diode
CW

EYP-RWL-1060-00750-4000-FLW01-0006Single Mode Laser Diode

Wavelength: 1060 nm
Power: 750 mW
Fabry Perot laser diode
Pulsed

TYPICAL APPLICATIONS FOR Single Mode Laser diodes

Atomic Clock

Illumination

Interferometry

Metrology
